Sync output configures DB150 Operating Mode & connects the DB150 to expansion boosters LocoNet is more than just wiring, it is a fully integrated train control system. For future expansion, LocoNet offers you full access to advanced features such as track level feedback for train detection, signaling & automated operation without the need to run a separate bus. The LocoNet wiring scheme gives you a very reliable system for sending your commands to the track and controlling your trains. All connections are made with 6 conductor telco jacks & wire.
LocoNet Expansion Network for easy reliable system hook up and future system expansion. Track Status indicator shows voltage and signal type (DCC or "Zero Stretch" Analog Signal for conventional operation.) Auto resetting over temperature & short circuit protection.ĭigitrax Boosters are safe for use with all scales because they are multi scale selectable for N through G scale operations.The power supply you use should be within this range and should be overload protected for a maximum output of 4.5 amps DC.
Minimum input voltage: 12V AC or DC, Maximum input voltage: 22V AC or 28V DC. Accepts either 50/60Hz AC or DC input from your existing power supply.Many command station options are user customizable. Built in 5 Amp Digital Command Control Booster Rated at 80VA.Genesis uses Paged Programming method exclusively. Built in broadcast write only programmer.Use with any LocoNet throttle (DT400 series, DT300 series, DT100 series, DT200, UT2, UT1, BT2, Computer throttle, LocoPalm Throttle and new Digitrax and LocoNet Certified throttles to come soon).Up to 22 throttles in command station mode.
DB150 gives you the ultimate in expandability! DB150 is also available separately.įull LocoNet Capabilities. The latest generation of Digitrax Command Stations and Boosters require DC power and will not function on AC power supplies.DB150 Command Station/Booster with Intelligent AutoReverseĭB150 is shipped as part of the Super Empire Builder Sets. The chart below shows the model of the Digitrax DCC Command Station or Booster with the recommended Power Supply.
